Description Specification
Engine Model Cat® C9.3B Tier 4 Final
Gross Power 375 hp (280 kW)
Engine Speed 1880 rpm
Weight 38,450 lb (17 740 kg)
Fuel Capacity 130.5 gal (494 L)
DEF Capacity 11.8 gal (44.7 L)
Hydraulic Tank Capacity 30.4 gal (115 L)
Wheelbase 125.0" (3175 mm)
Ground Clearance 24.7” (627 mm)
Transport Width 9’ 11” (3.03 m)
Transport Length 29’ 11” (9.12 m)
Travel Speed (low) 0-5.2 mph (0-8.4 km/h)
Travel Speed (high) 0-12.3 mph (0-19.8 km/h)
Cutting Path - 624 8' 0" (2.44 m)
Cutting Path - 825 8’ 4” (2.54 m)
Max Single Cut Diameter - 624 8.0" (203 mm)
Max Single Cut Diameter - 825 16.0" (406 mm)
Max Mowing Diameter - 624 4.0" (102 mm)
Max Mulching Diameter - 825 16.0” (406 mm)
Base configuration includes 30.5L-32 26PR Tires, winch ready, and 825 mulching head.
