Mini Excavators 305 CR - Tier 4 / Stage V

An extensive line of Cat® mini hydraulic excavators offers the performance to dig in and be productive on every job.

Download product brochure #1

Download product brochure #2

Download product brochure #3

Download product brochure #4

Mini Excavators 305 CR - Tier 4 / Stage V

An extensive line of Cat® mini hydraulic excavators offers the performance to dig in and be productive on every job.

Download product brochure #1

Download product brochure #2

Download product brochure #3

Download product brochure #4

1-800-268-1965

Request a Quote

Find a dealer near you

Units: US Metric

Air Conditioning System

Specification	Value
Air Conditioning	The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a or R1234yf (Europe) (Global Warming Potential = 1430). See label or instruction manual for gas refrigerant identification. The system contains 0.75 kg (1.65 lb), 0.90 kg (1.98 lb) or 1.0 kg (2.20 lb) of refrigerant which has a CO2 equivalent of 1.430 metric tonnes (1.576 tons) for R134a and 0.001 tonnes (0.001 tons) for R1234yf (Europe).

Air Conditioning

The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a or R1234yf (Europe) (Global Warming Potential = 1430). See label or instruction manual for gas refrigerant identification. The system contains 0.75 kg (1.65 lb), 0.90 kg (1.98 lb) or 1.0 kg (2.20 lb) of refrigerant which has a CO2 equivalent of 1.430 metric tonnes (1.576 tons) for R134a and 0.001 tonnes (0.001 tons) for R1234yf (Europe).

Units: US Metric

Blade

Specification	Value
Straight Blade Width	78 in 1980 mm
Straight Blade Height	15.4 in 390 mm
Angle Blade Width	78 in 1980 mm
Angle Blade Height	15.7 in 400 mm
Angle Blade - Left	25 degrees
Angle Blade - Right	25 degrees

Units: US Metric

Certification - Cab and Canopy

Specification	Value
Roll Over Protective Structure (ROPS)	ISO 12117-2:2008
Top Guard	ISO 10262:1998 Level I

Units: US Metric

Dimensions - Long Stick

Specification	Value
Dig Depth	144.5 in 3670 mm
Vertical Wall	100.8 in 2560 mm
Maximum Reach - Ground Level	229.7 in 5835 mm
Maximum Reach	235.8 in 5990 mm
Maximum Dig Height	210.8 in 5355 mm
Maximum Dump Clearance	151.4 in 3845 mm
Boom In Reach	101.6 in 2580 mm
Tail Swing without Counterweight	43.1 in 1095 mm
Tail Swing with Counterweight	47.2 in 1200 mm
Maximum Blade Height	15.2 in 385 mm
Maximum Blade Depth	23.4 in 595 mm
Boom Height - Shipping Position	74.6 in 1895 mm
O/A Shipping Height	100.4 in 2550 mm
Swing Bearing - Height	24.4 in 619 mm
O/A Undercarriage Length	101.6 in 2580 mm
Overall Shipping Length*	210.2 in 5340 mm
Boom Swing - Right	34.1 ° 865 mm
Boom Swing - Left	615 mm 24.2 °
Track Belt/Shoe Width	15.7 in 400 mm
Track Width	78 in 1980 mm
Ground Clearance	13.2 in 335 mm
Stick Length	63 in 1601 mm
Note	*Overall Shipping Length depends on blade position during shipment.

Units: US Metric

Dimensions - Standard Stick

Specification	Value
Dig Depth	134.6 in 3420 mm
Vertical Wall	91.9 in 2335 mm
Maximum Reach - Ground Level	220.1 in 5590 mm
Maximum Reach	226.6 in 5755 mm
Maximum Dig Height	205.3 in 5215 mm
Maximum Dump Clearance	145.7 in 3700 mm
Boom In Reach	101.2 in 2570 mm
Tail Swing without Counterweight	43.1 in 1095 mm
Tail Swing with Counterweight	47.2 in 1200 mm
Maximum Blade Height	15.2 in 385 mm
Maximum Blade Depth	23.4 in 595 mm
Boom Height - Shipping Position	71.7 in 1820 mm
O/A Shipping Height	100.4 in 2550 mm
Swing Bearing - Height	24.4 in 619 mm
O/A Undercarriage Length	101.6 in 2580 mm
Overall Shipping Length*	208.9 in 5305 mm
Boom Swing - Right	34.1 ° 865 mm
Boom Swing - Left	24.2 ° 615 mm
Track Belt/Shoe Width	15.7 in 400 mm
Ground Clearance	13.2 in 335 mm
Stick Length	53.2 in 1351 mm
Note	*Overall Shipping Length depends on blade position during shipment.

Units: US Metric

Engine

Specification	Value
Net Power	45 hp 33.6 kW
Engine Model	C1.7 Turbo
Net Power - 2,400 rpm - ISO 9249, 80/1269/EEC	45 hp 33.6 kW
Gross Power - 2,400 rpm - SAE J1995:2014	48.4 hp 36.1 kW
Bore	3.3 in 84 mm
Stroke	3.9 in 100 mm
Displacement	101 in³ 1.662 l
Emissions	The Cat® C1.7 engine meets U.S. EPA Tier 4 Final and EU Stage V emission standards.
Note	Advertised power is tested per the specified standard in effect at the time of manufacture.
Note (2)	Net power advertised is the power available at the flywheel when the engine is at the rated speed of 2400 rpm and the engine is installed with the factory configured fan, air intake system, exhaust system and alternator with a minimum alternator load.

Units: US Metric

Hydraulic System

Specification	Value
Pump Flow at 2,400 rpm	35 gpm 133 L/min
Operating Pressure - Equipment	3843 psi 265 bar
Operating Pressure - Travel	3843 psi 265 bar
Operating Pressure - Swing	2901 psi 200 bar
Auxiliary Circuit - Primary - Flow	21 gpm 80 L/min
Auxiliary Circuit - Primary - Pressure	3843 psi 265 bar
Auxiliary Circuit - Secondary - Flow	7 gpm 28 L/min
Auxiliary Circuit - Secondary - Pressure	3843 psi 265 bar
Digging Force - Stick - Standard	6362 lbf 28.3 kN
Digging Force - Stick - Long	5665 lbf 25.2 kN
Digging Force - Bucket	11061 lbf 49.2 kN
Note	Flow and pressure are not combinable. Under load, as flow rises pressure goes down.
Type	Load Sensing Hydraulics with Variable Displacement Piston Pump

Units: US Metric

Service Refill Capacities

Specification	Value
Cooling System	2.9 gal (US) 11 l
Engine Oil	1.6 gal (US) 6 l
Fuel Tank	17 gal (US) 63 l
Hydraulic Tank	16 gal (US) 60 l
Hydraulic System	20 gal (US) 75 l

Units: US Metric

Sound

Specification	Value
Operator Sound Pressure (ISO 6396:2008)	76 dB(A) 76 dB(A)
Average Exterior Sound Pressure (ISO 6395:2008)	97 dB(A) 97 dB(A)
Note	The declared dynamic operator sound pressure levels per ISO 6396:2008. The measurements were conducted with the cab doors and windows closed. *The labeled sound power level for the CE marked configurations when measured according to the test procedure and conditions specified in 2000/14/EC.

Units: US Metric

Sustainability

Specification	Value
Recyclability	96%

Units: US Metric

Swing System

Specification	Value
Machine Swing Speed	9 r/min 9 r/min
Boom Swing - Left	72 Degrees
Boom Swing - Right	50 Degrees

Units: US Metric

Travel System

Specification	Value
Travel Speed - High	3.1 mile/h 5 km/h
Travel Speed - Low	1.7 mile/h 2.8 km/h
Maximum Traction Force - High Speed	5553 lbf 24.7 kN
Maximum Traction Force - Low Speed	11353 lbf 50.5 kN
Ground Pressure - Minimum Weight	4 psi 27.3 kPa
Ground Pressure - Maximum Weight	4.7 psi 32.2 kPa
Gradeability - Maximum	30 degrees

Units: US Metric

Weight Increase from Minimum Configuration

Specification	Value
Counterweight	534 lb 242 kg
Long Stick	75 lb 34 kg
Steel Tracks with Pads	827 lb 375 kg
Angle Blade	225 lb 102 kg

Units: US Metric

Weights

Specification	Value
Operating Weight	12688 lb 5754 kg
Minimum Operating Weight with Canopy*	11016 lb 4996 kg
Maximum Operating Weight with Canopy**	12469 lb 5655 kg
Minimum Operating Weight with Cab*	11234 lb 5095 kg
Maximum Operating Weight with Cab**	12688 lb 5754 kg
Note (1)	*Minimum Weight is based on rubber tracks, operator, full fuel tank, standard stick, straight blade, no bucket and no extra counterweight.
Note (2)	**Maximum Weight is based on steel tracks with pads, operator, full fuel tank, long stick, straight blade, extra counterweight and no bucket.

ALL DAY COMFORT

Choose either a canopy or a sealed and pressurized cab which can be equipped with air conditioning, adjustable wrist rests, and a suspension seat to help keep you working comfortably all day long.

EASY TO OPERATE

Controls are easy to use and the intuitive Next Generation LCD monitor provides easy to read machine information. An advanced touchscreen monitor can also be equipped as an upgrade option.

STICK STEER TRAVEL MODE

Moving around the job site is even easier with the Cat Stick Steer option. Easily switch from traditional travel controls with levers and pedals to joystick controls to move the machine and to operate the blade. The benefit of less effort and improved control is in your hands!

BIG PERFORMANCE IN A COMPACT DESIGN

Strong lift and dig performance helps you get the job done faster. The compact radius design lets you access and work in the tightest areas. Dig-to-blade and dozer blade float allows for easy clean up. An angle blade is also an option for finished grading and easier backfilling applications.

SAFETY ON THE JOB SITE

Your safety is our top priority. The Cat mini excavator is designed to help keep you safe on the job. Courtesy work lights and a fluorescent retractable seat belt with optional seat belt reminder system are just a couple of the safety features we’ve built into the machine.

SIMPLE SERVICE FOR LESS DOWNTIME

Maintenance is quick and easy on the Cat mini excavator. Routine check points are easy to access at ground level through the side doors.

LOWER OPERATING COSTS

Equipped with features such as auto idle, auto engine shutdown, and efficient hydraulics with a variable displacement pump, the Cat mini excavator was designed with reducing your operating costs in mind.

UNMATCHED DEALER SUPPORT

Your Cat dealer is here to help you reach your business goals. From providing equipment solutions to operator training to service needs and beyond, your Cat dealer is ready to help.

ENGINE

Cat® C1.7 Turbo Engine (U.S. EPA Tier 4 Final)

HYDRAULICS

Smart Tech Electronic Pump

GUARDING

ROPS ISO 12117-2:2008

OTHER

Eco Drain

OPERATOR ENVIRONMENT

LED Front and Rear Lights

UNDERCARRIAGE

Rubber Belt (400 mm/15.7 in)
